RT-4E300S-110V Accessories
Product Groups
Accessories
Product Groups
Accessories
Application
Hydarulic System
Basic Information
| Unit | Motor Type | Motor Model | Voltages(V) | Frequency(Hz) | Input(W) | Current(A) | Speed(rpm) | Air Flow 20Pa (m³/h)) | Noise(dBA) | Capacitor(μF/250V) | Rotation | Insulation Class |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Axial fan motor | Single phase motor with capacitor | YWF4SP-300SC | 110 | 60 | 105 | 0.95 | 1550 | 2000 | 60 | 10 | Clockwise (from end-shield view) | B |
| Motor Protection | Temperature Rise | Protection Rating | Operating Type | Ambient Temperature | Bearings | Mounting | Electrical Connection | Apprvoals | Net Weight/Gross Weight(Kg) | Packing Dimensions(mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| Thermocontact 135±5°C | Max within 75K | IP54 | S1 | -30°C~60°C | Ball bearings | Vertical or horizontal | Lead wire silicon 4G 0.50mm2, length 100mm in terminal box | CE | 3.0/4.0 | 340*340*180 |
Wiring Diagram
Peformance - Air Flow
